Sound Rated Basic Automatic Door Bottom Seals With Side Edge

Sound Rated Basic Automatic Door Bottom Seals With Side Edge
Sound Rated Basic Automatic Door Bottom Seals With Side Edge Sound Rated Basic Automatic Door Bottom Seals With Side Edge Sound Rated Basic Automatic Door Bottom Seals With Side Edge Sound Rated Basic Automatic Door Bottom Seals With Side Edge

Large Image :  Sound Rated Basic Automatic Door Bottom Seals With Side Edge

Product Details:
Place of Origin: China
Brand Name: BHMFT
Certification: CE
Model Number: BH-M002
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: EXW price US$ 6.5-10.5/ set
Packaging Details: each one packed by a PE bag, 20 sets in a carton, carton size: 105*20*10cm, gross weight is about 12kgs per carton.
Delivery Time: 7-10 days after receive the payment
Payment Terms: T/T
Supply Ability: 2000 sets per week

Sound Rated Basic Automatic Door Bottom Seals With Side Edge

Description
Main Materials: Alumium Alloy Sealing Strips: Silicone Sealing Strips
Fixed Part: 201 SS Stainless Steel Type: Concealed With Side Edge
Size: 15*32-32mm Length: Can Do 250-1500mm
Regular Length: 800mm, 915mm And 1000mm Available Cut Length: 800mm- Can Cut To 700mm, 915mm- Can Cut To 800mm, 1000mm- Can Cut To 900mm
High Light:

Automatic Door Bottom Seals 1500mm

,

201 SS Automatic Door Bottom Seals

Aluminium Alloy Automatic Door Bottom Seals Concealed Drop Down Weatherstrips With Side Edge For Wooden Door or Metal Door



When it comes to soundproofing a door a tight seal is critical for proper sound control. Your largest gap is at the bottom of the door and nothing can seal that as well as an automatic door bottom.



Features:



Operated automatically by pressure against the door jamb on its adjustable strike (the copper bolt).
Adjust the adjustable strike (the round copper bolt) to achieve an optimum seal.
Fully morticed into a 15mm x 32mm groove into the bottom of single and double butt hinged timber and metal doors.

This item shape has the side edge, can fix it in the door bottom from the side edge.

Suitable for the wooden fire door, steel fire door, industry doors, hotel doors etc.
Prevent dust, hot and cold air, noisy sound, light from door bottom
High quality silicone seal with long life service.
Beautiful 6063 aluminum body with gold color copper bolt.



Specifications:



Item No.:  BH-M002
Min/Max Gap: 3mm to 14mm
Finish: Clear Anodised
Fixing: Concealed Screw Fix, Fixing holes are pre-slotted
Seal: Grey Silicon Rubber
Fixed Part: Stainless Steel, Including Screws
Size can do: 250-1500mm
Regular length: 800mm, 915mm, 1000mm

Regular length can cut length:

800mm - cancut to 700mm,

915mm - can cut to 800mm,

1000mm - can cut to 900mm.







Sound Rated Basic Automatic Door Bottom Seals With Side Edge 0

Sound Rated Basic Automatic Door Bottom Seals With Side Edge 1Sound Rated Basic Automatic Door Bottom Seals With Side Edge 2Sound Rated Basic Automatic Door Bottom Seals With Side Edge 3
